Nippon Chemi-Con 330μF 250V dc Aluminium Electrolytic Capacitor, Through Hole 22 (Dia.) x 30mm +105°C 22mm 10mm 30mm [EKMS251VSN331MP30S]; 170-0701
0₫
Mã kho: 1700701
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 330 µF |
Voltage | 250 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 22 (Dia.) x 30mm |
Length | 30mm |
Minimum Operating Temperature | -25°C |
Diameter | 22mm |
Maximum Operating Temperature | +105°C |
Lifetime | 3000h |
Lead Pitch | 10mm |
Series | KMS |
Tolerance | ±20% |
Ripple Current | 1.29Arms |
Dissipation Factor | 0.0015 |
Leakage Current | <=3√CV μA @ 5 min |
