Nippon Chemi-Con 1800μF 250V dc Aluminium Electrolytic Capacitor 35 (Dia.) x 50mm +105°C 35mm 10mm 50mm [EKMS251VSN182MA50S]; 161-5383
0₫
Mã kho: 1615383
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 1800 µF |
Voltage | 250 V dc |
Mounting Type | Snap-In |
Technology | Electrolytic |
Dimensions | 35 (Dia.) x 50mm |
Length | 50mm |
Minimum Operating Temperature | -25°C |
Diameter | 35mm |
Maximum Operating Temperature | +105°C |
Lifetime | 3000h |
Lead Pitch | 10mm |
Series | KMS |
Tolerance | ±20% |
Ripple Current | 3.98Arms |
Dissipation Factor | 0.0015 |
Leakage Current | =3CV μA @ 5 min |
