Nippon Chemi-Con 180μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 22 (Dia.) x 35mm +105°C 22mm 10mm 35mm [EKMQ401VSN181MP35S]; 841-4731
0₫
Mã kho: 8414731
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 180 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 22 (Dia.) x 35mm |
| Length | 35mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 22mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 2000h |
| Series | KMQ |
| Leakage Current | ≤ 3 CV μA |
| Ripple Current | 0.95Arms |
| Tolerance | ±20% |
