Nippon Chemi-Con 1000μF 250V dc Aluminium Electrolytic Capacitor, Through Hole 30 (Dia.) x 40mm +105°C 30mm 10mm 40mm [EKMQ251VSN102MR40S]; 170-0648
0₫
Mã kho: 1700648
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 1000 µF |
Voltage | 250 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 30 (Dia.) x 40mm |
Length | 40mm |
Minimum Operating Temperature | -25°C |
Diameter | 30mm |
Maximum Operating Temperature | +105°C |
Lifetime | 2000h |
Lead Pitch | 10mm |
Series | KMQ |
Ripple Current | 2.2Arms |
Leakage Current | ≤ 3 CV μA |
Tolerance | ±20% |
