Nippon Chemi-Con 470μF 200V dc Aluminium Electrolytic Capacitor, Through Hole 22 (Dia.) x 30mm +105°C 22mm 10mm 30mm [EKMQ201VSN471MP30S]; 170-0665
0₫
Mã kho: 1700665
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 470 µF |
Voltage | 200 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 22 (Dia.) x 30mm |
Length | 30mm |
Minimum Operating Temperature | -25°C |
Diameter | 22mm |
Maximum Operating Temperature | +105°C |
Lifetime | 2000h |
Lead Pitch | 10mm |
Series | KMQ |
Tolerance | ±20% |
Leakage Current | ≤ 3 CV μA |
Ripple Current | 1.45Arms |
