Nippon Chemi-Con 33000μF 16V dc Aluminium Electrolytic Capacitor, Through Hole 31 (Dia.) x 45mm +105°C 31mm 10mm [EKMH160VSN333MR45S]; 144-4022
0₫
Mã kho: 1444022
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 33000 µF |
| Voltage | 16 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 31 (Dia.) x 45mm |
| Height | 45mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 31mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 10mm |
| Series | KMH |
| Ripple Current | 4.30Arms |
| Tolerance | ±20% |
| Leakage Current | 3 mA |
| Dissipation Factor | 0.004 |
| Polarised | Polar |
