Nippon Chemi-Con 22000μF 16V dc Aluminium Electrolytic Capacitor, Through Hole 26.4 (Dia.) x 45mm +105°C 26.4mm 10mm [EKMH160VSN223MQ45S]; 144-3922
0₫
Mã kho: 1443922
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 22000 µF |
Voltage | 16 V dc |
Mounting Type | Snap-In |
Technology | Electrolytic |
Dimensions | 26.4 (Dia.) x 45mm |
Height | 45mm |
Minimum Operating Temperature | -40°C |
Diameter | 26.4mm |
Maximum Operating Temperature | +105°C |
Lifetime | 2000h |
Lead Pitch | 10mm |
Series | KMH |
Ripple Current | 3.32Arms |
Tolerance | ±20% |
Leakage Current | 3 mA |
Polarised | Polar |
Dissipation Factor | 0.004 |
