![Nippon Chemi-Con APSG160ELL821MJB5S 1749924](http://nguyenxuong.com/cdn/shop/products/R1749924-01_444x338.jpg?v=1594318543)
Nippon Chemi-Con 820μF 16V dc Aluminium Polymer Capacitor, Through Hole 10 Dia. x 11.5mm +105°C 10mm 5mm [APSG160ELL821MJB5S]; 174-9924
0₫
Mã kho: 1749924
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 820 µF |
Voltage | 16 V dc |
Mounting Type | Through Hole |
Technology | Polymer |
Dimensions | 10 Dia. x 11.5mm |
Height | 11.5mm |
Minimum Operating Temperature | -55°C |
Diameter | 10mm |
Maximum Operating Temperature | +105°C |
Lifetime | 1000h |
Lead Pitch | 5mm |
Series | PSG |
Equivalent Series Resistance | 12mΩ |
Tolerance | ±20% |
Ripple Current | 5400mArms |
Leakage Current | 500 μA |
Polarised | Polar |
Dissipation Factor | 0.0012 |
