Nichicon 3.3μF 160V dc Aluminium Electrolytic Capacitor, Through Hole 6.3 x 11mm +105°C 6.3mm 2.5mm [UVZ2C3R3MED]; 862-1838
by Nichicon
0₫
Mã kho: 8621838
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 3.3 µF |
| Voltage | 160 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 6.3 x 11mm |
| Height | 11mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 6.3mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 1000h |
| Lead Pitch | 2.5mm |
| Series | VZ |
| Tolerance | ±20% |
| Ripple Current | 30mA |
| Leakage Current | 92.8 μA |
