Nichicon 100μF 63V dc Aluminium Electrolytic Capacitor, Through Hole 10 x 12.5mm +105°C 10mm 5mm [UVZ1J101MPD1TD]; 862-1731
by Nichicon
0₫
Mã kho: 8621731
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 100 µF |
| Voltage | 63 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 10 x 12.5mm |
| Height | 12.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 1000h |
| Lead Pitch | 5mm |
| Series | VZ |
| Tolerance | ±20% |
| Leakage Current | 189 μA |
| Ripple Current | 215mA |
