Nichicon 15000μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 25 (Dia.) x 50mm +105°C 25mm 12.5mm [UVY1V153MRD]; 167-7794
by Nichicon
0₫
Mã kho: 1677794
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 15000 µF |
Voltage | 35 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 25 (Dia.) x 50mm |
Height | 50mm |
Minimum Operating Temperature | -55°C |
Diameter | 25mm |
Maximum Operating Temperature | +105°C |
Lifetime | 1000h |
Lead Pitch | 12.5mm |
Series | VY |
Ripple Current | 3.1A |
Leakage Current | 15750 μA |
Tolerance | ±20% |
