Nichicon 22μF 63V dc Aluminium Electrolytic Capacitor, Through Hole 5 x 11mm +85°C 5mm 2mm [UVR1J220MDD]; 862-3291
by Nichicon
0₫
Mã kho: 8623291
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 22 µF |
Voltage | 63 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 5 x 11mm |
Height | 11mm |
Minimum Operating Temperature | -40°C |
Diameter | 5mm |
Maximum Operating Temperature | +85°C |
Lead Pitch | 2mm |
Lifetime | 2000h |
Series | VR |
Ripple Current | 100mA |
Tolerance | ±20% |
Leakage Current | 41.58 μA |
