Nichicon 1000μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 12.5 (Dia.) x 20mm +85°C 12.5mm 5mm [UVK1V102MHD]; 475-8006
by Nichicon
0₫
Mã kho: 4758006
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1000 µF |
| Voltage | 35 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 12.5 (Dia.) x 20mm |
| Height | 20mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 12.5mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 2000h |
| Lead Pitch | 5mm |
| Series | VK |
| Ripple Current | 1.15A |
| Leakage Current | 3 μA, 4 μA |
| Tolerance | ±20% |
