Nichicon 470μF 16V dc Aluminium Electrolytic Capacitor, Surface Mount 10 (Dia.) x 10mm +85°C 10mm 4.5mm [UUR1C471MNL1GS]; 739-3037
by Nichicon
0₫
Mã kho: 7393037
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 470 µF |
Voltage | 16 V dc |
Mounting Type | Surface Mount |
Technology | Electrolytic |
Dimensions | 10 (Dia.) x 10mm |
Height | 10mm |
Minimum Operating Temperature | -40°C |
Diameter | 10mm |
Maximum Operating Temperature | +85°C |
Lifetime | 2000h |
Lead Pitch | 4.5mm |
Series | UR |
Leakage Current | 225.6 μA |
Polarised | Polar |
Tolerance | ±20% |
Ripple Current | 330mA |
