Nichicon 100μF 350V dc Aluminium Electrolytic Capacitor, Through Hole 20 (Dia.) x 40mm +105°C 20mm 10mm [UPW2V101MRD]; 173-3406
by Nichicon
0₫
Mã kho: 1733406
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 100 µF |
| Voltage | 350 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 20 (Dia.) x 40mm |
| Height | 40mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 20mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 8000h |
| Series | PW |
| Ripple Current | 290mA |
| Tolerance | ±20% |
