Nichicon 2.2μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 10 (Dia.) x 16mm +105°C 10mm 5mm [UPW2G2R2MPD]; 167-7820
by Nichicon
0₫
Mã kho: 1677820
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2.2 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 10 (Dia.) x 16mm |
| Height | 16mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 5mm |
| Lifetime | 5000h |
| Series | PW |
| Tolerance | ±20% |
| Ripple Current | 27mA |
