Nichicon 2200μF 25V dc Aluminium Electrolytic Capacitor, Through Hole 12.5 (Dia.) x 35.5mm +105°C 12.5mm 5mm [UPW1E222MHD3]; 165-3621
by Nichicon
0₫
Mã kho: 1653621
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2200 µF |
| Voltage | 25 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 12.5 (Dia.) x 35.5mm |
| Height | 35.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 12.5mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 5mm |
| Lifetime | 7000h |
| Series | PW |
| Leakage Current | 4 μA |
| Ripple Current | 2.51A |
| Tolerance | ±20% |
