Nichicon 15μF 16V dc Aluminium Electrolytic Capacitor, Through Hole 4 (Dia.) x 7mm +105°C 4mm 1.5mm [UPW1C150MDD]; 173-3042
by Nichicon
0₫
Mã kho: 1733042
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 15 µF |
| Voltage | 16 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 4 (Dia.) x 7mm |
| Height | 7mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 4mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 1.5mm |
| Series | PW |
| Leakage Current | 4 μA |
| Tolerance | ±20% |
| Ripple Current | 65mA |
