Al-THT -40°C to 105°C 400V 10uF 10x16mm [UCY2G100MPD]; 187-2421
by Nichicon
0₫
Mã kho: 1872421
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 10 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 10 Dia. x 16mm |
| Height | 16mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 5mm |
| Lifetime | 10000h |
| Series | CY |
| Leakage Current | 0.26 (Short Term) μA |
| Ripple Current | 150mA |
| Tolerance | ±20% |
| Dissipation Factor | 0.0024 |
| Polarised | Polar |
