Nichicon 10μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 10 (Dia.) x 20mm +105°C 10mm 5mm [UCS2G100MPD]; 165-3663
by Nichicon
0₫
Mã kho: 1653663
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 10 µF |
Voltage | 400 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 10 (Dia.) x 20mm |
Height | 20mm |
Minimum Operating Temperature | -40°C |
Diameter | 10mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 5mm |
Lifetime | 8000h |
Series | CS |
Ripple Current | 350mA |
Tolerance | ±20% |
