Nichicon 4.7μF 350V dc Aluminium Electrolytic Capacitor, Through Hole 10 x 20mm +125°C 10mm 5mm [UBT2V4R7MPD8]; 173-3253
by Nichicon
0₫
Mã kho: 1733253
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 4.7 µF |
Voltage | 350 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 10 x 20mm |
Height | 20mm |
Minimum Operating Temperature | -25°C |
Diameter | 10mm |
Maximum Operating Temperature | +125°C |
Lead Pitch | 5mm |
Lifetime | 2000h |
Series | BT |
Tolerance | ±20% |
Leakage Current | 0.04 CV + 100 μA (CV1000 @ 1 minute), 0.1 CV + 40 μA (CV1000 @ 1 minute) |
Ripple Current | 53mArms |
