Nichicon 10μF 100V dc Aluminium Electrolytic Capacitor, Through Hole 8 x 11.5mm +125°C 8mm 3.5mm [UBT2A100MPD8]; 167-1112
by Nichicon
0₫
Mã kho: 1671112
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 10 µF |
| Voltage | 100 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 8 x 11.5mm |
| Height | 11.5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +125°C |
| Lead Pitch | 3.5mm |
| Lifetime | 2000h |
| Series | BT |
| Leakage Current | 4 μA |
| Tolerance | ±20% |
| Ripple Current | 150mArms |
| Equivalent Series Resistance | 1.5Ω |
