Nichicon 2200μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 18 x 35.5mm +125°C 18mm 7.5mm [UBT1V222MHD8]; 167-1217
by Nichicon
0₫
Mã kho: 1671217
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2200 µF |
| Voltage | 35 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 18 x 35.5mm |
| Height | 35.5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 18mm |
| Maximum Operating Temperature | +125°C |
| Lifetime | 10000h |
| Lead Pitch | 7.5mm |
| Series | BT |
| Leakage Current | 4 μA |
| Tolerance | ±20% |
| Equivalent Series Resistance | 25mΩ |
| Ripple Current | 2790mArms |
