Nichicon 470μF 6.3V dc Aluminium Polymer Capacitor, Through Hole 6.3 x 8mm +105°C 6.3mm 2.5mm [RS80J471MDNASQJT]; 851-3917
by Nichicon
0₫
Mã kho: 8513917
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 470 µF |
| Voltage | 6.3 V dc |
| Mounting Type | Through Hole |
| Technology | Polymer |
| Dimensions | 6.3 x 8mm |
| Height | 8mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 6.3mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 2.5mm |
| Lifetime | 5000h |
| Series | S8 |
| Equivalent Series Resistance | 8mΩ |
| Leakage Current | 740 μA |
| Ripple Current | 5000mArms |
| Tolerance | ±20% |
