Nichicon 390μF 450V dc Aluminium Electrolytic Capacitor, Through Hole 30 (Dia.) x 40mm +105°C 30mm 10mm [LGL2W391MELB40]; 167-1492
by Nichicon
0₫
Mã kho: 1671492
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 390 µF |
| Voltage | 450 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 30 (Dia.) x 40mm |
| Height | 40mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 30mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 10mm |
| Series | GL |
| Leakage Current | 1.25 mA |
| Ripple Current | 1.28A |
| Tolerance | ±20% |
