![NIC Components NRZJ471M25V10X12.5F 7374395](http://nguyenxuong.com/cdn/shop/products/R7374373-01_0535481f-c263-4ba5-aea9-259ca0cb9080_444x116.jpg?v=1594381511)
NIC Components 470μF 25V dc Aluminium Electrolytic Capacitor, Through Hole 10 (Dia.) x 12.5mm +105°C 10mm 5mm [NRZJ471M25V10X12.5F]; 737-4395
0₫
Mã kho: 7374395
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 470 µF |
Voltage | 25 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 10 (Dia.) x 12.5mm |
Height | 12.5mm |
Minimum Operating Temperature | -40°C |
Diameter | 10mm |
Maximum Operating Temperature | +105°C |
Lifetime | 10000h |
Lead Pitch | 5mm |
Series | NRZJ |
Leakage Current | 0.01 CV or 3 μA @ 2 min |
Equivalent Series Resistance | 53mΩ |
Tolerance | ±20% |
Ripple Current | 1.7A |
