KEMET 220μF 250V dc Aluminium Electrolytic Capacitor, Snap-In 22 x 40mm +105°C 22mm 40mm [PEH536SAE3220M3]; 434-0841
by KEMET
0₫
Mã kho: 4340841
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 220 µF |
| Voltage | 250 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 22 x 40mm |
| Height | 40mm |
| Length | 40mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 22mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 4600 h @ +105 °C/250V dc/Ir, 6000h @ +105 °C/250V dc |
| Series | PEH536 |
| Leakage Current | 0.03 mA |
| Tolerance | ±20% |
| Ripple Current | 810mA |
| Equivalent Series Resistance | 450mΩ |
| Polarised | Polar |
