KEMET 4700μF 100V dc Aluminium Electrolytic Capacitor 35 x 55mm +105°C 35mm 55mm [PEH536PDH4470M3]; 173-5093
by KEMET
0₫
Mã kho: 1735093
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 4700 µF |
| Voltage | 100 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 35 x 55mm |
| Height | 55mm |
| Length | 55mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 4600 h @ +105 °C/100V dc/Ir, 6000h @ +105 °C/100V dc |
| Series | PEH536 |
| Equivalent Series Resistance | 42mΩ |
| Ripple Current | 4.3A |
| Tolerance | ±20% |
| Leakage Current | 0.03 mA |
| Polarised | Polar |
