KEMET 6000μF 450V dc Aluminium Electrolytic Capacitor, Stud Mount 76.6 x 224.2mm +85°C 76.6mm 224.2mm [PEH200YX460BQB2]; 311-1197
by KEMET
0₫
Mã kho: 3111197
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 6000 µF |
| Voltage | 450 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 76.6 x 224.2mm |
| Height | 224.2mm |
| Length | 224.2mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 76.6mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 19000 h @ +85 °C/450V dc/Ir |
| Series | PEH200 |
| Polarised | Polar |
| Leakage Current | 12.1 mA |
| Ripple Current | 18.5A |
| Tolerance | ±20% |
| Equivalent Series Resistance | 12mΩ |
