KEMET 47000μF 63V dc Aluminium Electrolytic Capacitor, Stud Mount 66.6 x 109.2mm +85°C 66.6mm 109.2mm [PEH200MO5470MB2]; 183-5295
by KEMET
0₫
Mã kho: 1835295
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 47000 µF |
| Voltage | 63 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 66.6 x 109.2mm |
| Height | 109.2mm |
| Length | 109.2mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 66.6mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 15000 h @ +85 °C/63V dc/Ir |
| Series | PEH200 |
| Leakage Current | 12.883 mA |
| Ripple Current | 21.8A |
| Equivalent Series Resistance | 10mΩ |
| Tolerance | ±20% |
| Polarised | Polar |
