KEMET 3000μF 40V dc Aluminium Electrolytic Capacitor, Through Hole 20 x 37mm +150°C 20mm 37mm [PEG225KJ4300QE1]; 172-6807
by KEMET
0₫
Mã kho: 1726807
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 3000 µF |
| Voltage | 40 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 20 x 37mm |
| Height | 37mm |
| Length | 37mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 20mm |
| Maximum Operating Temperature | +150°C |
| Lifetime | 2000 h @ +150 °C/Ir |
| Series | PEG225 |
| Equivalent Series Resistance | 35mΩ |
| Ripple Current | 7.3A |
| Leakage Current | 360 μA |
| Polarised | Polar |
| Tolerance | -10 → +30% |
