KEMET 33μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 20 x 37mm +105°C 20mm 37mm [PEG124VJ2330QL1]; 173-1906
by KEMET
0₫
Mã kho: 1731906
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 33 µF |
Voltage | 400 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 20 x 37mm |
Length | 37mm |
Minimum Operating Temperature | -40°C |
Diameter | 20mm |
Maximum Operating Temperature | +105°C |
Lifetime | 22000 h @ +105 °C/Ir |
Series | PEG124 |
Ripple Current | 304mA |
Tolerance | -10 → +30% |
Polarised | Polar |
Equivalent Series Resistance | 1.6Ω |
Leakage Current | 83.2 μA |
