KEMET 10μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 13 x 32mm +105°C 13mm 32mm [PEG124VE2100QL1]; 226-7182
by KEMET
0₫
Mã kho: 2267182
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 10 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 13 x 32mm |
| Length | 32mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 13mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 10000 h @ +105 °C/Ir |
| Series | PEG124 |
| Equivalent Series Resistance | 5.9Ω |
| Ripple Current | 116mA |
| Leakage Current | 28 μA |
| Polarised | Polar |
| Tolerance | -10 → +30% |
