KEMET 47μF 100V dc Aluminium Electrolytic Capacitor, Through Hole 13 x 29mm +105°C 13mm 29mm [PEG124PD247VQL1]; 172-6751
by KEMET
0₫
Mã kho: 1726751
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 47 µF |
| Voltage | 100 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 13 x 29mm |
| Length | 29mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 13mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 10000 h @ +105 °C/Ir |
| Series | PEG124 |
| Polarised | Polar |
| Leakage Current | 32.2 μA |
| Tolerance | -10 → +30% |
| Equivalent Series Resistance | 1.5Ω |
| Ripple Current | 206mA |
