KEMET 2200μF 25V dc Aluminium Electrolytic Capacitor, Through Hole 20 x 37mm +125°C 20mm 37mm [PEG124HJ422VQL1]; 226-6965
by KEMET
0₫
Mã kho: 2266965
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2200 µF |
| Voltage | 25 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 20 x 37mm |
| Length | 37mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 20mm |
| Maximum Operating Temperature | +125°C |
| Lifetime | 22000 h @ +125 °C/Ir |
| Series | PEG124 |
| Polarised | Polar |
| Leakage Current | 4 μA |
| Ripple Current | 1.803A |
| Equivalent Series Resistance | 60mΩ |
| Tolerance | -10 → +30% |
