KEMET 3300μF 100V dc Aluminium Capacitor, Stud Mount 36 (Dia.) x 52mm +85°C 36mm 12.8mm [ALS71A332DA100]; 144-3169
by KEMET
0₫
Mã kho: 1443169
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 3300 µF |
| Voltage | 100 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 36 (Dia.) x 52mm |
| Height | 52mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 36mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 22000h |
| Lead Pitch | 12.8mm |
| Series | ALS71 |
| Tolerance | ±20% |
| Leakage Current | 6000 μA |
| Polarised | Polar |
| Ripple Current | 9.3A |
| Equivalent Series Resistance | 99mΩ |
