KEMET 82000μF 25V dc Aluminium Capacitor, Chassis Mount 36 (Dia.) x 105mm +85°C 36mm 12.8mm [ALS70A823DF025]; 144-3099
by KEMET
0₫
Mã kho: 1443099
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 82000 µF |
| Voltage | 25 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 36 (Dia.) x 105mm |
| Height | 105mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 36mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 22000h |
| Lead Pitch | 12.8mm |
| Series | ALS70 |
| Ripple Current | 16.1A |
| Polarised | Polar |
| Leakage Current | 6000 μA |
| Tolerance | ±20% |
| Equivalent Series Resistance | 20mΩ |
