KEMET 8200μF 450V dc Aluminium Capacitor, Chassis Mount 90 (Dia.) x 131mm +85°C 90mm 31.8mm [ALS70A822QM450]; 144-3156
by KEMET
0₫
Mã kho: 1443156
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 8200 µF |
| Voltage | 450 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 90 (Dia.) x 131mm |
| Height | 131mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 90mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 31.8mm |
| Lifetime | 40000h |
| Series | ALS70 |
| Equivalent Series Resistance | 28mΩ |
| Ripple Current | 28.8A |
| Leakage Current | 6000 μA |
| Tolerance | ±20% |
| Polarised | Polar |
