KEMET 7500μF 400V dc Aluminium Capacitor, Chassis Mount 77 (Dia.) x 115mm +85°C 77mm 31.8mm [ALS70A752NJ400]; 144-3451
by KEMET
0₫
Mã kho: 1443451
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 7500 µF |
| Voltage | 400 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 77 (Dia.) x 115mm |
| Height | 115mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 77mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 40000h |
| Lead Pitch | 31.8mm |
| Series | ALS70 |
| Ripple Current | 23.7A |
| Equivalent Series Resistance | 29mΩ |
| Leakage Current | 6000 μA |
| Polarised | Polar |
| Tolerance | ±20% |
