KEMET 1300μF 500V dc Aluminium Capacitor, Chassis Mount 51 (Dia.) x 82mm +85°C 51mm 22.2mm [ALS70A132KE500]; 144-3410
by KEMET
0₫
Mã kho: 1443410
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1300 µF |
| Voltage | 500 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 51 (Dia.) x 82mm |
| Height | 82mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 51mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 22.2mm |
| Lifetime | 36000h |
| Series | ALS70 |
| Equivalent Series Resistance | 203mΩ |
| Ripple Current | 11.1A |
| Tolerance | ±20% |
| Leakage Current | 6000 μA |
| Polarised | Polar |
