KEMET 1F 25V dc Aluminium Capacitor, Chassis Mount 90 (Dia.) x 169mm +85°C 90mm 31.8mm [ALS70A105QW025]; 144-3101
by KEMET
0₫
Mã kho: 1443101
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1 F |
| Voltage | 25 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 90 (Dia.) x 169mm |
| Height | 169mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 90mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 40000h |
| Lead Pitch | 31.8mm |
| Series | ALS70 |
| Equivalent Series Resistance | 5mΩ |
| Ripple Current | 41.3A |
| Polarised | Polar |
| Leakage Current | 6000 μA |
| Tolerance | ±20% |
