KEMET 2200μF 500V dc Aluminium Electrolytic Capacitor, Stud Mount 77 x 146mm +85°C 77mm 146mm [ALS31A222NP500]; 173-2031
by KEMET
0₫
Mã kho: 1732031
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2200 µF |
| Voltage | 500 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 77 x 146mm |
| Height | 146mm |
| Length | 146mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 77mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 20000 h @ +85 °C/500V dc/Ir, 40000 h @ +85 °C/500V dc |
| Series | ALS31 |
| Polarised | Polar |
| Equivalent Series Resistance | 80mΩ |
| Ripple Current | 14.3A |
| Tolerance | ±20% |
| Leakage Current | 6 mA |
