KEMET 470μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 40 x 75mm +85°C 40mm 10mm 75mm [ALP20A471DE400]; 107-870
by KEMET
0₫
Mã kho: 107870
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 470 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 40 x 75mm |
| Height | 75mm |
| Length | 75mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 40mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 26000 h @ +85 °C/400V dc/Ir |
| Lead Pitch | 10mm |
| Series | ALP20 |
| Tolerance | -10 → +30% |
| Ripple Current | 2.8A |
| Leakage Current | 1.128 mA |
| Polarised | Polar |
| Equivalent Series Resistance | 240mΩ |
