Capacitor Snap In Alu 12000uF 63V ALC80 [ALC80A123DF063]; 185-8586
by KEMET
0₫
Mã kho: 1858586
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 12000 µF |
| Voltage | 63 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 35 Dia. x 50mm |
| Height | 50mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 13000h |
| Lead Pitch | 10mm |
| Series | ALC80 |
| Equivalent Series Resistance | 34mΩ |
| Ripple Current | 10.62A |
| Tolerance | ±20% |
| Leakage Current | 2.268 mA |
| Polarised | Polar |
