KEMET 3300μF 350V dc Aluminium Capacitor, Snap-In 45 Dia. x 105mm +85°C 45mm 22.5mm [ALC70C332FP350]; 181-3420
by KEMET
0₫
Mã kho: 1813420
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 3300 µF |
| Voltage | 350 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 45 Dia. x 105mm |
| Depth | 105mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 45mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 22.5mm |
| Lifetime | 30000h |
| Series | ALC70 |
| Tolerance | ±20% |
| Ripple Current | 15.8A |
| Equivalent Series Resistance | 47Ω |
| Leakage Current | 6.93 mA |
| Polarised | Polar |
