KEMET 560μF 500V dc Aluminium Capacitor, Snap-In 40 Dia. x 50mm +85°C 40mm 10mm [ALC70A561EF500]; 181-3468
by KEMET
0₫
Mã kho: 1813468
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 560 µF |
| Voltage | 500 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 40 Dia. x 50mm |
| Depth | 50mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 40mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 30000h |
| Lead Pitch | 10mm |
| Series | ALC70 |
| Equivalent Series Resistance | 370Ω |
| Leakage Current | 1.68 mA |
| Ripple Current | 6A |
| Tolerance | ±20% |
| Polarised | Polar |
