KEMET 560μF 450V dc Aluminium Capacitor, Snap-In 35 Dia. x 50mm +85°C 35mm 10mm [ALC70A561DF450]; 181-3426
by KEMET
0₫
Mã kho: 1813426
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 560 µF |
Voltage | 450 V dc |
Mounting Type | Snap-In |
Technology | Electrolytic |
Dimensions | 35 Dia. x 50mm |
Depth | 50mm |
Minimum Operating Temperature | -40°C |
Diameter | 35mm |
Maximum Operating Temperature | +85°C |
Lead Pitch | 10mm |
Lifetime | 30000h |
Series | ALC70 |
Ripple Current | 6.5A |
Tolerance | ±20% |
Leakage Current | 1.512 mA |
Equivalent Series Resistance | 253Ω |
Polarised | Polar |
