KEMET 270μF 400V dc Aluminium Capacitor, Through Hole 30 Dia. x 35mm +105°C 30mm 10mm [ALA8DA271CC400]; 176-2504
by KEMET
0₫
Mã kho: 1762504
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 270 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 30 Dia. x 35mm |
| Height | 35mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 30mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Series | ALA8D |
| Equivalent Series Resistance | 327.2 (10 kHz) mΩ, 558.2 (100 Hz) mΩ |
| Ripple Current | 1.67 (100 Hz) A, 4.62 (10 kHz) A |
| Leakage Current | 648 μA |
| Automotive Standard | AEC-Q200 |
| Tolerance | ±20% |
| Polarised | Polar |
