KEMET 180μF 16V dc Aluminium Polymer Capacitor, Surface Mount 8.3 x 8.3 x 7.5mm +105°C 3.2mm 8.3mm [A765KH187M1CLAE016]; 173-1746
by KEMET
0₫
Mã kho: 1731746
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 180 µF |
| Voltage | 16 V dc |
| Mounting Type | Surface Mount |
| Technology | Polymer |
| Dimensions | 8.3 x 8.3 x 7.5mm |
| Height | 7.5mm |
| Length | 8.3mm |
| Depth | 8.3mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 3.2mm |
| Series | A765 |
| Equivalent Series Resistance | 16mΩ |
| Ripple Current | 2.8A |
| Polarised | Polar |
| Leakage Current | 576 μA |
| Tolerance | ±20% |
