KEMET 220μF 6.3V dc Aluminium Polymer Capacitor, Surface Mount 5.3 x 5.3 x 7mm +105°C 1.4mm 5.3mm [A765BG227M0JLAE020]; 173-4090
by KEMET
0₫
Mã kho: 1734090
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 220 µF |
| Voltage | 6.3 V dc |
| Mounting Type | Surface Mount |
| Technology | Polymer |
| Dimensions | 5.3 x 5.3 x 7mm |
| Height | 7mm |
| Length | 5.3mm |
| Depth | 5.3mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 1.4mm |
| Series | A765 |
| Equivalent Series Resistance | 20mΩ |
| Polarised | Polar |
| Tolerance | ±20% |
| Leakage Current | 300 μA |
| Ripple Current | 2.7A |
